Stonex R80 Motorized Total Station

Description

Stonex R80 Motorized Total Station

Stonex R80 Motorized Total Station for classic surveying and setting out work is perfect for high-precision survey areas. This includes monitoring rail traffic, checking buildings, bridges, dams and landslide areas.
The Stonex R80 Motorized Total Station uses the latest automatic prism recognition and positioning technology. It therefore has a high angle measurement accuracy of 0.5 “-1”. The R80 has a range finding accuracy of 1 mm + 1 ppm (prism) and a reflectorless range finding with a range of 1,000 m.

Windows CE 7.0 is installed as the operating system on this motorized total station. Each user can choose the software that best suits their needs. Since the R80 also supports SDK and an external control protocol for software development, the device is the first choice for all users who also want to develop their own applications.

OnePole Solution TS+GPS with Cube-a Software

OnePole Solution combines the millimeter positioning accuracy of a prism measurement with the advantage of measuring points not visible from the TS through the GPS Receiver. A total station needs local control points on which it can be set. These points must be visible from the station and therefore the line of sight has to be free of obstacles. An RTK GPS receiver can determine its position in seconds with centimeter level accuracy using data from satellites. The ability to combine and use both systems simultaneously greatly improves surveying efficiency.

Advantages of the system:

The OnePole Solution allows you to work simultaneously with TS and GPS
TS and GPS (and diastimeter) can be simultaneously connected to the controller using Bluetooth
Change the measurement mode from TS to GPS by one simple tap on the always accessible switch button
Reduce prism search times through auto aiming to the current GPS position
Easily setup your TS position by Station On Point and Free Station/Resection programs
View on Google Maps your TS and GPS surveys

Your advantages:

Fast, accurate and reliable
for classic surveying and setting out work
automatic prism detection and positioning technology
High precision

Scope of delivery:

Charger, 2 batteries
Adjustment plate
Transport case
USB cable
Tool kit
Cleaning set
Reflective sheets RP30 x 4 and RP 60 x 1
USB stick with operating instructions and video descriptions
rain protection
Pen for the display operation
cube link software

Technical Features

Angle measurement accuracy 0.5 “-1”.
Distance measurement accuracy 1 mm + 1 ppm (prism)2″ accuracy
High-precision long-range measurements: up to 1,000 m in reflectorless mode
and up to 5,000 m with a single prism with millimeter accuracy
one-pole solution with additional GNSS receiver possible
long-term recordings
constant monitoring of measuring points possible by using cube-h24
Long range Bluetooth

Cube-h24 Solution

Cube-h24 has been designed to perform operations to check movements of points in natural places or artificial structures, considered to be at risk of stability. In general, the materialization of the points is made with prisms used for topography, in order to determine the real distances from a station point. It is however possible to use points marked on a reflecting surface.

Cube-h24 allows to:

Set up surveys and calculation procedures, in order to compare the coordinates of the points subject to control in subsequent interventions
