Olympus IPLEX GAir Videoscopes

Description

Olympus IPLEX GAir Videoscopes

Olympus IPLEX GAir Videoscopes combines maneuverability and brightness at long distances, so you can reach distant targets quickly and identify defects.

Inspect Farther, Faster

Long-distance remote visual inspection (RVI) is fast and efficient with the IPLEX GAir videoscope. Flexible and maneuverable, the videoscope’s 30-meter (98-foot) or 20-meter (65-foot) insertion tube can easily move through complex piping systems with multiple elbows. When you reach your inspection target, you can examine it with high-quality, wide-view images and bright LED illumination.

Long Range Pipe Inspection

The IPLEX GAir videoscope combines maneuverability and brightness at long distances, so you can reach distant targets quickly and identify defects.

Maneuver through complex pipes: the guide head reduces friction and easily passes over joints between pipes while the universal push rod adaptor enables a smooth passage through pipes and elbows
Precise articulation regardless of length: pneumatic articulation with an integrated air compressor delivers fine control, and the Tapered Flex™ insertion tube balances stiffness and flexibility for easy maneuvering
Know your location: the gravity sensor rotates live images regardless of the scope’s orientation, and the insertion length indicator enables you to track the insertion tube’s position

Convenient Videoscope Features

Quickly change scopes: the waterproof scope unit can be swapped with no special tools
Comfortable viewing angle: place the detachable LCD screen where you want
Easy to transport: the compact, wheeled carrying case is easy to move—when you’re ready to inspect, the wheels lock to keep the unit stationary

Advanced Remote Visual Inspection Tools

Built with the high-quality image sensor, brightness, and advanced image processing the IPLEX series is known for, the IPLEX GAir videoscope enables you to see more during your inspection.

Ultra-bright illumination: powerful LEDs light up large spaces without the intensity decay common to other long videoscopes

Automatic brightness adjustments: the PulsarPic processor actively adjusts the illumination to consistently provide the right level of brightnes

See more of the pipe: 220-degree fish-eye optical tip adaptor shows the side wall and forward view at the same time

Real-time distortion correction: the videoscope can show distortion-corrected images with 120°, 180°, and 220° equivalent fields of view

Clear images in large spaces: the long exposure mode enables a better probability of detection in very large spaces

Efficient in oily environments: the oil-clearing tip adaptor draws oil away from the lens for clearer images so you spend less time withdrawing the insertion tube to clean the lens
