Hitachi Oxford X-Met 8000 Expert Geo Handheld XRF Analyzer

Description

Hitachi Oxford X-Met 8000 Expert Geo Handheld XRF Analyzer

Hitachi Oxford X-Met 8000 Expert Geo Handheld XRF Analyzer designed for the on-site screening of environmental sediments and soils. The X-MET8000 Geo allows environmental testing to be carried out quickly and at high volumes, reducing the level of lab analysis required and the cost associated with it.

The X-MET8000 Geo uses novel BOOST technology, which means the system has detection limits that are low enough for the fast and accurate measurement of critical elements (e.g., US EPA Method 6200 RCRA and priority elements).

The system has integrated GPS that allows analysis results to be combined with geolocation data for the creation of site maps with contaminant locations. The geodata provided uses Trimble receivers to provide accurate localized data.

Specifications:

Analyzer

– Handheld EDXRF analyser.
– Large area, high resolution Silicon Drift (SDD) detector.
– Rh target X-ray tube (4 W; 50 kV max., 200 μA max.).
– Automatic 6-position filter changer.
– Measurement spot size: 10.7 mm x 9.4 mm.
– Operating temperature: -10 °C to +50 °C.

Screen and operating system

– 4.3” Blanview touch screen.
– Display resolution: 480 (H) x 800 (V) dots.
– 16 GB internal memory.
– Capable of holding 100,000 results with spectra and images (if camera fitted).
– Bluetooth, WiFi and USB data transfer.
– Graphical user interface available in 13 languages: Chinese traditional and simplified, English, Finnish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Spanish and Russian.

Calibration

– Factory-loaded robust fundamental parameters (FP) and empirical calibrations (traceable to certified reference materials) available for a wide variety of applications (e.g. alloys, RoHS, wood, car catalysts…).
– Customer specific calibrations with optional calibration software.

Analytical range

– From Mg to U, up to 35 elements depending on application.

Batteries

– Rechargeable, removable, located inside handle.
– 6.2 Ah Li-ion batteries (Quantity: 2).
– Up to 10-12 hours battery life.
– 110/230 V 50/60 Hz battery charger.

Connectivity ports

– USB 2.0.
– Bluetooth 2.0 (EDR).
– WiFi 802.11 b/g.

PC software (standard)

– Spectrum Display – enables to select analysis condition, collect, view and compare samples spectra.
– Report Generator – enables the creation of customised reports.

Optional PC software functionality

– Calibration software – enables the user to create a customised empirical calibration using customer’s standards for unique applications

Package includes:

– Hitachi X MET 8000 Expert geo.
– Check sample.
– Battery charger, with UK, US, Euro and Australia plug adapters (charging time: ~8 hours).
– Two Li-ion batteries.
– USB cable.
– USB memory stick containing the User Manual and the Safety Manual (available in 13 languages).
– Light travel stand with safety shield.
– Light radiation shield.
– Background plate.
– Holster and belt.
– WiFi and Bluetooth connectivity.
– Warranty card
– Calibration Certificate
