Hilti PS 1000-B X-Scan Concrete Scanner

Description

Hilti PS 1000-B X-Scan Concrete Scanner

Hilti PS 1000-B X-Scan Concrete Scanner Radar Detection System is designed to produce easy-to-read images of what’s inside concrete structures within minutes. Locating rebar, post tension cable, metal and plastic conduits, glass-fiber cables, voids and wood in dry concrete are made simple with the PS 1000-B X-Scan.

Package content

1x Scanner PS 1000
5x Reference grid PSA 12 (mm, 600×600)
2x Reference grid PSA 14 (mm, 1200×1200)
1x Torque wrench 6kt S3 1,8 NM
1x Concrete adhesive tape PUA 90
1x Hand strap
1x Marker pen PUA 70
2x Battery pack PSA 81 ROW
1x Mains adapter PUA 81 (02)
1x Memory card PSA 95 SDHD – 4 GB
1x Case PS 1000

Efficient concrete scanner for structural analysis and to locate embedded objects in multiple layers

Max. detection depth for object localization: 300 mm
Accuracy of depth indication: <100 mm: ±10 mm, >100 mm: ±15 %
Localization accuracy: ±10 mm

Features

Provides real-time view of the inside of concrete structures and generates accurate images automatically for direct on-site evaluation
Three scan modes for specific applications Quick scan detection, Quick scan recording and Image scan
Displays a top view and cross sections of the scan in 2D and 3D for easy object mapping and multi layer

identification

Compact all-in-one design offers easy operation, plus unmatched data visualization means hundreds of square metres of concrete can be inspected in a day
Powerful monitor for in-depth, on-site scan analysis plus PC software for subsequent data evaluation and documentation

Applications

Locating rebars, tendons, metal and plastic conduits, glass-fiber cables, voids and wood in dry concrete structures at depths of up to 300 mm
Minimizing hitting concealed objects when drilling anchor holes or through holes, breaking out openings and in diamond coring and sawing work
Rebar extension (post-installed rebar connections) in structural applications
Inspection of floors, decks, slabs, balconies, etc. in structures such as tunnels, bridges and buildings
Detection of voids and cavities
