Creaform HandySCAN 700 3D Scanner

Description

Creaform HandySCAN 700 3D Scanner

Creaform HandySCAN 700 3D Scanner the truly portable metrology-grade 3d scanners provides a very high accuracy and speed of scanning. This device can easily scan any type of physical object and provide the most reliable and effective results. The new generation scanners have undergone a complete re-engineering process, and as a result, they now are capable of operating with more efficiency. They have become more portable and faster at performing accurate, high resolution scans. The result should meet immediately digitizing 7 precision lasers and Dynamic binding TRUaccuracy. HandySCAN 700 provides precision scanning up to 0.03 mm with a resolution of 0.05 mm. It is the perfect solution for those industries that require fast and accurate assessment of the maximum fitness items.

480,000 measurements / sec
Scan Area: 275h250 mm
Light source: 7 lasers
Resolution: 0.05 mm
Accuracy: 30 microns

Proven and trusted technology

Offering the best value for money, a smart purchase because of its accessible price and high-quality performance. Designed and manufactured in North America and with more than 5,000 users already, this proven and trusted technology demonstrates Creaform’s prioritization of attentive service and reliability.

– Best price / performance option
– Designed and manufactured in North America
– More than 5,000 users worldwide
– Supported by a global team of engineers and technicians

Portability

Using triangulation on optical reflectors to determine its relative position to the part, this handheld 3D scanner is a stand-alone device that does not require a tripod or any external tracking device to operate. Compact enough to fit into a small suitcase, it can be brought anywhere and used in any environmental conditions without its performance being affected.

– Lightweight and small
– 0.85 kg (1.9 lb)
– Fits into a suitcase
– Self-positioning with dynamic referencing
– On-the-go scanning
– Use it in-house or on site
– Quick set-up
– Up and running in less than 2 minutes

Simplicity & versatility

With its user-friendly interface and ergonomic design, this 3D measurement solution is easy to use and has a short learning curve regardless of the user’s experience or expertise level. Its versatility enables users to scan various objects no matter the part size, complexity, material, or color—all with the same device.

– Plug and play
– Simple user interface and real-time visualization
– Masters complex and difficult surfaces
– One device for all shapes and sizes

TECHNICAL SPECIFICATIONS

Package includes:

– Creaform HandySCAN 700
– VXelements Software
– Power supply
– USB cable
– Calibration plate
– Carrying case
– USB cable
– 2,000 positioning targets
– 3 Year warranty on Parts and Labor
