Artec Ray 3D Scanner

Description

Artec Ray 3D Scanner

Artec Ray 3D Scanner is suitable indoors and outdoors, with or without a power source. Indeed, its internal battery lasts up to four hours. the Artec Ray is a professional laser 3D scanner made by Artec, a manufacturer from Luxembourg.

To obtain a 3D point cloud of an object, the Artec Ray uses LiDAR (Light Detection and Ranging) 3D scanning technology.

Scan up to 110 m away with this professional LIDAR solution.

KEY FEATURES:

– Range – Up to 110 m
– Ranging error – <0.7 mm @ 15 m
– Angular accuracy – 25 arcseconds
– Range noise, 90% reflectivity – 0.12 mm @ 15 m
– Range noise, 10% reflectivity – 0.3 mm @ 15 m
– Export formats – OBJ, PLY, WRL, STL, AOP, ASCII, Disney PTEX,E57, XYZRGB, BTX, PTX, CSV, DXF, XML

SPECIFICATIONS TABLE:

– Recommended Work Range: 0.7 mm @ 15 m High Quality Mode & <0.9 mm @ 15 m High Sensitivity Mode
– Ranging error: 0.7 mm @ 15 m High Quality Mode & <0.9 mm @ 15 m
– Range noise, 90% reflectivity: 0.12 mm @ 15 m High Quality Mode & 0.25 mm @ 15 m High Sensitivity Mode
– Range noise, 10% reflectivity: 0.3 mm @ 15 m High Quality Mode & 0.7 mm @ 15 m High > Sensitivity Mode
– Angular accuracy: 25 arcsecs
– Speed, points/second: 208,000
– Scanning modes: Autonomous or via USB
– Color: Two fully integrated 5 megapixel cameras

SPECIAL FEATURES:

– High accuracy long-range laser 3D scanner, ideal for precise capture of large objects
– Submillimeter accuracy
– Scan large vehicles, pipes or buildings.
– Ideal for reverse engineering, inspection and construction.
– Scan large objects both indoors and outdoors!
– Ultra-high precision, fast laser 3D scanner with submillimeter precision.
– Cleanest 3D data capture for minimum post-processing time

APPLICATIONS:

– Industrial design and manufacturing
– Healthcare
– VR
– E-commerce
– Science and education
– Forensics
– Art and design

INCLUDES:

(1X) ARTEC Ray Scanner
(2X) Batteries Li-Ion 14V of 49Wh (Removable)
(1X) Power supply with connection cable to RAY
(1X) Charger for 2 batteries at the same time
(1X) USB cable to connect the scanner to a PC (3 Meter)
(1X) Tread Adapter
(2X) Micro 32 GB SD cards with an SD card backup system
(1X) Carrying Case
(1X) Transport bag
